CT1270

SynAVIO NetAV HD (AVoIP)

  • A simplified and unified transmitter and receiver design

  • A total solution for display extender, splitter, switcher and matrix

  • Fully work with your existing LAN infrastructure without installation

  • Extend HDMI signal up to 180m (600ft) by single Cat.5 cable.

  • Supports Video/Audio/USB/IR/UART over IP

  • Use conventional Ethernet L2 Switch for extension and distribution, and can be cascaded by the L2 Ethernet switches for longer distance

  • Supports Graphic/ Video mode selection for different applications and the latency is about 80 ~100 ms

Asset 10New Release_Gradient.png

CT1273

SynAVIO NetAV HD Zero (AVoIP)

  • A total Integrate LAN switch inside to support daisy chain

  • Supports lossless latency (under 1 ms)

  • Extend HDMI signal up to 180m (600ft) by single Cat.5 cable

  • Support video resolution up to 1080p@60Hz

  • Supports Stereo Audio over IP, independent to HDMI extension

  • Supports IR (20KHz~60KHz) extension over IP

  • Compliance with HDMI 1.4 and HDCP 1.4

Asset 15New Release_Gradient1.png

CT1278

SynAVIO Network KVM / Cloud KVM

  • Network KVM

    • Supports 1080p H.264 Encoder

    • Supports HDMI Input and Passthrough

  • Cloud KVM

    • ​In the era of digital innovation, the ability to control systems remotely without compromising security is paramount. This is where our unique solution, KVM Cloud, shines.

    • Our Cloud-Based Solution is Ideal for those who seek flexibility and seamless access from anywhere. Our cloud product ensures your data is secure while providing you with the freedom of remote management.

    • KVM Cloud is a versatile, secure, and efficient solution for remote control of KVM devices.

    • KVM Cloud caters to your specific needs, ensuring optimal performance and security. Experience the future of remote control with KVM Cloud today.

Asset 13New Release_Gradient1.png

CT1500

SynAVIO NetAV 4K HDMI 2.0 over IP Multicast

  • Supports resolution up to 4K2K@60 4:4:4 8bits

  • Flexible and scalable UHD Video Broadcasting by Gigabit Ethernet LAN/Switch

  • One to one, one to many & multi-casting broadcasting architecture

  • Supports full frequency IR signal from 20KHz to 60KHz

  • Full Duplex RS-232 control up to 115,200 bps through connector

  • Easy Dip Switch matching for multi-casting group configuration

  • Supports Video Wall function

  • Wall mounting housing design for easy and robust installation

Asset 13New Release_Gradient1.png

CT2000

SynAVIO NetAV 4K HDMI 2.0 over IP Multicast

  • Supports resolution up to 4K2K@60 4:4:4

  • Flexible and scalable UHD Video Broadcasting by 10 Gigabit Ethernet LAN/Switch

  • Extends the transmission over multi-mode optic cable up to 300m (990ft) (OM3)/400m (1320ft) (OM4)

  • Light compress with less than 100us latency for 4K2K@60 4:4:4

  • Supports full frequency IR signal from 20KHz to 60KHz

  • Full Duplex RS-232 control up to 115,200 bps through connector

  • Supports software to configure & upgrade device and to control the switching operation of the various signal types

  • Supports Video Wall & Multi-view function

  • Wall mounting housing design for easy and robust installation

Asset 13New Release_Gradient1.png

CT2010

SynAVIO NetAV 4K HDMI 2.0 over IP Multicast

  • Supports resolution up to 4K2K@60 4:4:4

  • Flexible and scalable UHD Video Broadcasting by 10 Gigabit Ethernet LAN/Switch

  • Extends the transmission over multi-mode optic cable up to 300m (990ft) (OM3)/400m (1320ft) (OM4)

  • Light compress with less than 100us latency for 4K2K@60 4:4:4

  • Supports full frequency IR signal from 20KHz to 60KHz

  • Full Duplex RS-232 control up to 115,200 bps through connector

  • Supports software to configure & upgrade device and to control the switching operation of the various signal types

  • Supports Video Wall & Multi-view function

  • Wall mounting housing design for easy and robust installation


CS1820

SynEdge AIoT Box for Streamer

  • Supports 1080p HDMI input and 4K60 HDMI output

  • 10/100/1000Mbps Ethernet and WiFi 6

  • Supports RS232

  • Supports 1080p H.264 Encoder Server, such UDP, TCP, RTP, RTSP, RTMP, SRT etc.

  • Supports 4K H.264 decode from Streaming Server

  • Can provide Cloud CMS (Central Management System) for signage application


CS1830

SynEdge AIoT Box with 4K Decoder

  • Edge AIoT – Realtek RTD1619B

  • Quard-Core A55 1.9GHz CPU and Mali-G57 GPU

  • 1.6 TOPS NPU

  • Supports Streaming Function :

  • RTSP,TCP, UDP, RTP, RTMP, RTMPS, SRT
    Video and Picture Decoding Functions :

  • AVI Main Profilc, Level 5.1

  • H.264 HP @ Level 5.1

  • H.264 MVC SHP@L4.1

  • HD MPEG2(up to MP@HL1080i), ISO/IFO VOB/TS

  • HD JPEG with 32K x 32K maximum resolution

  • Full-pixel JPEG decode with high resolution zoom-in


CS1831

SynEdge AIoT SMARC

  • Quard-Core A55 1.9GHz CPU and Mali-G57 GPU

  • 1.6 TOPS NPU​

       Video and Picture Decoding Functions :

  • AVI Main Profilc, Level 5.1

  • H.264 HP @ Level 5.1

  • H.264 MVC SHP@L4.1

  • HD MPEG2(up to MP@HL1080i), ISO/IFO VOB/TS

  • HD JPEG with 32K x 32K maximum resolution

  • Full-pixel JPEG decode with high resolution zoom-in


CS1832

SynEdge AIoT Real.Pi

  • Edge AIoT – Realtek RTD1619B

  • Quard-Core A55 1.9GHz CPU and Mali-G57 GPU

  • 1.6 TOPS NPU
    Video and Picture Decoding Functions :

  • AVI Main Profilc, Level 5.1

  • H.264 HP @ Level 5.1

  • H.264 MVC SHP@L4.1

  • HD MPEG2(up to MP@HL1080i), ISO/IFO VOB/TS

  • HD JPEG with 32K x 32K maximum resolution

  • Full-pixel JPEG decode with high resolution zoom-in


CS1835

SynEdge AIoT

       Edge AIoT – Genio G350

  • Quard-Core A53 2.0GHz CPU and Mali-G52 GPU

  • 0.3 TOPs NPU

       Video and Picture Decoding Functions :

  • 1080P60 Decode, H.265/H.264/VP9

  • 1080P60 Encode, H.265/H.264

       Interface :

  • UART*2 (1.8V or 3.3V) / UART*1 (1.8V) / I2C*4 (1.8V) / SPI*1 (3.3V)

  • USB 2.0 Hub 1 to 4 / USB 2.0 OTG *1 / JTAG*1 (1.8V) / Torch LED*ˊ (5V/GND/PWM)

       Access Control :

  • Relay switch *1 (12V/1A) / Wiegand (5V) *1 26biits 34 bits /  PWM out (1.8V)



CS1880

SynEdge AIoT

  • CPU – Quad-core Arm Cortex-A53 processor @ up to 2.0GHz

  • MCU – Arm Cortex-M4 real-time core @ up to 400+MHz

  • GPU – 2D and 3D Vivante GPUs

  • VPU

    • 1080p60 H.265/H.264 video decoder (h.265，VP9，h.264，VP8)

    • 1080p60 H.264 video encoder

  • System Memory – 4GB LPDDR3 RAM

  • Storage --  32 GB eMMC 5.1 and  MicroSD card slot

  • Display

    • HDMI output

    •  2-lane MIPI DSI connector

  • Camera – 2-lane MIPI CSI connector

  • Audio – 3.5 mm headphone jack, and digital audio output via HDMI

  • Networking

    • Gigabit Ethernet (10/100/1000 Mbps) RJ45 jack

    • 4-pin USB Wi-Fi connector (for USB Wi-Fi module)

  • USB – 4x USB 2.0 ports

  • Expansion – 40-pin GPIO header with UART, SPI, I2C, and PWM functions

  • Power Supply – 5V/3A via USB Type-C port

  • Mechanical – 85 × 56 mm
