  • Supports up to 4K60Hz HDMI output

  • Supports Mirror or Extend Display

  • Supports Windows 10/11, Mac, and Chrome OS.

  • Supports PD 3.0 (up to 100W charging ability)

  • Supports 3.5mm Phone Jack (TRRS)

  • Supports 3.5mm Mic Phone Jack

  • Only one of TRRS output and microphone output can be selected for us

USB TypeC to 4K60 HDMI w/ audio

SynVio Dock | DK502

Call Now

  • Supports HDMI output resolution up to 4K@60Hz

  • Supports Mirror or Extend Display

  • Supports USB 3.0 high speed transmission up to 5Gbps

  • Supports PD 3.0 (up to 100W charging ability)

USB TypeC to 4K60 HDMI

SynVio Dock | DK503

Call Now

  • A compact size TypeC travel docking

  • Supports HDMI output resolution up to 4K@30Hz, including Mirror and Extend Display

  • Supports 3*USB-A 3.0 high speed transmission up to 5Gbps

  • Supports Gigabit Ethernet RJ45 port

  • Supports PD 3.0 (up to 60W charging ability)

6 in 1 USB TypeC Docking

SynVio Dock | DK506

Call Now

  • A compact size USB-C travel docking

  • Supports HDMI output (up to 8K@30Hz) or DisplayPort Output (up to 8K30Hz)

  • Supports Dual output display 4K@60Hz ( MST Mode + DSC 1.2)

  • Supports USB-A 3.0 Hub for high-speed transmission (up to 5Gbps)

  • Supports Gigabit Ethernet RJ45 port for stable internet connection

  • Supports SD & TF Card Reader available, compatibility SDXC

  • Supports 2 ports 5V/1.5A

  • Supports PD 3.0 (up to 100W charging ability)

10 in 1 USB TypeC MST Docking

SynVio Dock | DK510

Call Now

  • Dual USB-C (DP Alt-Mode) inputs

  • Easily switch via physical button or keyboard hotkey

  • HDMI 1.4 output up to 4K@30Hz

  • USB-A 3.2 Gen1 (5Gbps), and one port supports Keyboard hot-key switching

  • Supports USB-C PD 3.0 (up to 100W) pass-through (60W recommended output)

  • No driver required, and compatible with major USB-C DP Alt-Mode devices

  • Premium Aluminum Design : Lightweight and portable

Dual USB-C (DP Alt-Mode) KVM Docking

SynVio Dock | DK511

Call Now

  • Switch video and audio sources between 2*USB-C devices

  • Click a button to switch the input signal source

  • Supports HDMI resolution up to 4K@60Hz

  • Add 2*USB-A and 1*USB-C port provides 5Gbps data signaling rate

  • USB-C PD3.0 100W charging ability

  • Single port plug-in maximum charging 20V/4A. If both Port1 and Port2 have devices connected

    • ​The maximum power of Port1 is 20V/3.00A (60W)

    • The maximum power of Port2 is 9V/2.22A (20W)

USB-C to HDMI KVM Docking Switch

SynVio Dock  | DK512

Call Now

  • 1 HDMI Input (up to 4K@60) & 1 HDMI Bypass Output (up to 4K@60)

  • Capture resolution: up to 1080p@60Hz

  • USB 3.1 Gen1 connection to 2 PCs for fast data transfer

  • Supports USB Share HID Control

  • UVC 1.0 & UAC 1.0 compliant

  • USB-powered, no external adapter needed

  • PC software available for detailed control & settings

  • Compatible with QuickTime, OBS, XSplit, vMix & more

USB Sharing Box

SynVio Dock | DK515

Call Now

  • A Compact, Portable, Lightweight Aluminum design

  • Supports HDMI 2.1 8K@60Hz & 4K@120Hz with DSC function

  • HDMI 2.1 also supports 7680x4320@30Hz and is backward compatible with 4K resolution without DSC

  • Thunderbolt 3 compatible

  • Requires a USB-C port which supports “DisplayPort Alternative Mode” (not all USB-C ports/systems support Alternative Mode functionality.)

USB TypeC to 8K HDMI Adapter

SynVio Dock | DK518

#1
2024 Q1

NO.1


  • A Hybrid Capture/Docking Hub

  • TypeC USB 3.1 4K60 MJPEG/4K30 RAW capture with HDMI 2.0 input and passthrough

  • TypeC DisplayPort Alt-Mode to HDMI 4K60 output

  • Supports PD charging (Passthrough mode, up to 100W)

  • It not only makes your notebook become a monitor but also makes your laptop output to a HDMI TV (monitor) (mirror mode / extend mode)

USB TypeC Hybrid CapDocking

SynVio Dock | DK520

#1
2024 Q1

2024
Q1


  • Allows a USB-C laptop and an Android Smartphone to share one HDMI monitor and all connected USB peripherals

  • Supports USB-C (DisplayPort Alt-Mode) or HDMI input devices , and HDMI + UVC output. (by Mode selection)

  • Supports USB-A 3.0 *2, Gigabit Ethernet RJ45 for USB-C UVC or USB-C devices. (by Mode selection)

  • Supports USB-C PD 3.0 (up to 100W charging ability)

USB-C / HDMI Video Docking

SynVio Dock | DK525

2024
Q1

  • HDMI 2.0a compliant, supports resolutions up to 4K@60Hz

  • Fully compliant with HDCP 2.2 / HDCP 1.x

  • Backward compatible with HDMI 1.4

  • Supports 4K → 1080p downscaling on output Port #2

  • Supports Deep Color up to 36-bit (12-bit per color)

  • Maximum TMDS data rate up to 6.0 Gbps per lane

  • Hardware-based HDCP engine for enhanced reliability

  • EDID re-detection via reset button

  • USB firmware upgrade support

  • Embedded CEC / RCP hardware

  • Plug & play, no driver required

HDMI 2.0 1x2 Splitter

SynVio Node | HD240

2024
Q1

  • HDMI 2.0a compliant, and HDCP 2.2 / HDCP 1.4 compliant

  • 1x HDMI input to 2x HDMI outputs

  • Supports resolutions up to:

  • 4K@60Hz 4:4:4 8-bit

  • 4K@60Hz 4:2:0 10-bit (HDR10 pass-through)

  • Video bandwidth up to 18Gbps (600MHz)

  • HDR10 pass-through (no HDR processing or conversion)

  • Built-in EDID management:

  • Preset EDID modes

  • EDID learning from connected display

  • Selectable 4K → 1080p downscaling via DIP switch (per output)

HDMI2.0a 1x2 Splitter

SynVio Node | HD242

2024
Q1

  • HDMI 2.0a compliant, and HDCP 2.2 / HDCP 1.4 compliant

  • Supports 4K2K@60 4:4:4 8bits

  • Supports HDR1, which is 4K2K@60 4:2:0 10bits2

  • Controllable 4K to 1080P downscale using dip switch

  • Wide frequency range: 25MHz~600MHz

  • Video bandwidth: 18Gbps

  • Supports audio extraction via Toslink & stereo

  • Supports resolution downscaling from 4K2K to 1080P!

  • Supports default EDID and EDID learning from display

  • Supports xvYCC, x.v.Color& Deep Color

  • Micro-USB firmware update for expanding compatibility

  • HDMI Audio Format: PCM2/5.1/7.1, Dolby 5.1/7.1, DTS 5.1/7.1

  • Optical Audio Format: PCM2, Dolby 7.1, DTS 7.1

  • Easy installation​

HDMI2.0a 1x4 Splitter

SynVio Node | HD245

2024
Q1

  • HDMI 2.0b compliant

  • Supports video resolutions up to 4K2K@60Hz (4:4:4, 8-bit) and 8K@30Hz (4:2:0, 8-bit)

  • HDR support: 4K2K@60Hz (4:2:0, 10-bit)

  • HDCP 2.2 and HDCP 1.4 compliant

  • Video bandwidth up to 18Gbps (600MHz)

  • Supports xvYCC, x.v.Color, and Deep Color

  • Input selection via front panel button or IR remote control

  • Front panel LED indicators for power, output, and selected input status

  • Built-in input equalization and output pre-emphasis

  • Compact metal enclosure with easy installation

HDMI 2.0b 4x1 Switch

SynVio Node | HD254

2024
Q1

  • HDMI 2.0a compliant

  • Supports resolutions up to 4K2K@60Hz (4:4:4, 8-bit)

  • HDR support: 4K2K@60Hz (4:2:0, 10-bit)

  • HDCP 2.2 / HDCP 1.4 compliant

  • Video bandwidth up to 18Gbps (600MHz)

  • Supports xvYCC, x.v.Color, and Deep Color

  • USB-C Power Delivery up to 10W (PD 3.0, 5V/2A max)

  • Input selection via front panel button or IR remote control

  • Front panel LED indicators for input status

  • Built-in input equalization and output pre-emphasis

  • Compact metal enclosure with easy installation

HDMI 2.0a 4x1 & USB-C Switch

SynVio Node | HD257

2024
Q1

  • Converts HDMI 2.0 video to 12G / 6G / 3G / HD-SDI

  • Supports resolutions up to 4K2K@60Hz (12G-SDI)

  • Two SDI outputs with low jitter performance

  • HDMI loop-out for local monitoring

  • Supports embedded HDMI audio up to 7.1 channels

  • Built-in analog stereo audio embedder (2ch)

  • Fully digital conversion with no video or audio degradation

  • Compact metal enclosure for professional environments

HDMI 2.0 to SDI Converter

SynVio Node | HD292
