HD220
HD220-2

HD220

HDMI 2.0a Audio Extractor & Embedder

  • Extract Audio from HDMI 2.0 signal

  • HDMI 2.0 signal with audio embedded

2024
Q1

hd231 icon.png
HD221
HD221-2

HD221

HDMI 2.1 Audio Extractor & Embedder

  • HDMI 2.1 compliant

  • Supports up to 8K60 4:2:0 10bits, 8K30 4:4:4 & 4K2K 120Hz

  • Supports HDR1, which is 4K2K@60 10bits/12bits2 & Dolby Vision

  • Supports VRR(Variable Refresh Rate) & ALLM(Auto Low Latency Mode)*

  • HDCP 2.3 and 1.4 compliant

  • Supports resolution downscaling from 8K to 4K & 4K to 1080P and upscaling from 4K to 8K & 1080P to 4K

  • Supports audio extraction or insertion via stereo & Toslink

  • Supports CEC & ARC bypass and ARC audio extraction via Toslink

2024
Q1

hd231 icon.png
HD231
HD231-2
HD231-3

HD231

HDMI1.4 4K30 Splitter

  • Splits HDMI input to two HDMI output (displays)

  • Supports Full HD video

  • HDMI 1.4a compliant and HDCP1.4 compliant

  • Supports HDMI CEC Link

  • Plug-and-play: no software installation required

  • Supports FW update by USB

Call
Now

hd231 icon.png
hd231產品內容_產品圖-12
hd231產品內容_產品圖-13
HD240

HD240

HDMI2.0 4K60 Splitter

  • Splits HDMI input to two displays

  • Supports up to 4K@60 video

  • HDMI 2.0 MHL 2.2  compliant and HDCP 2.2 compliant

  • Supports HDMI CEC Link

  • Supports downscaling from 4K60 to 1080p60 for 1080p60 monitor using

  • Plug-and-play: no software installation required

  • Supports FW update by USB

Call
Now

hd240 icon.png
HD242
HD242-2
HD242-3

HD242

HDMI 2.0a Splitter with EDID Management

  • 1x2 HDMI 2.0 Splitter with built-in & User Adjustable EDID Management

  • Supports 4K2K@60 4:4:4 8bits and HDR, which is 4K2K@60 4:2:0 10bits

  • Supports audio extraction via Toslink & RCA

  • Supports resolution downscaling from 4K2K to 1080P

  • Supports default EDID and EDID learning from display

  • HDMI Audio Format: PCM2/5.1/7.1, Dolby 5.1/7.1, DTS 5.1/7.1

  • Optical Audio Format: PCM2, Dolby 5.1, DTS 5.1 (4) Downscale 4K Dolby Vision content

  • Micro-USB firmware update for expanding compatibility

Call
Now

hd240 icon.png
HD243-11
HD243-12
HD243-2

HD243

1x2 HDMI 2.0a Splitter with Audio Extractor

  • HDMI2.0a compliant

  • Supports 4K2K@60 4:4:4 8bits

  • Supports HDR1, which is 4K2K@60 4:2:0 10bits2

  • Controllable 4K to 1080P downscale using dip switch

  • HDCP 2.2 and 1.4 compliant

  • Supports audio extraction via Toslink

  • Micro-USB firmware update for expanding compatibility

  • HDMI Audio Format: PCM2/5.1/7.1, Dolby 5.1/7.1, DTS 5.1/7.1

  • Optical Audio Format: PCM2, Dolby 5.1, DTS 5.1

  • Easy installation

Call
Now

hd240 icon.png
HD247
HD247-2
HD247-3

HD247

1x2 HDMI 2.1 4K120 Splitter with Audio Extractor

  • Supports up to 4K2K 120Hz 4:4:4/4:2:2/4:2:01 and HDR, which is 4K2K@60 4:2:0 10bits/12bits & Dolby Vision

  • Supports VRR(Variable Refresh Rate) & ALLM(Auto Low Latency Mode)*

  • Supports CEC pass-through on input & output 2

  • HDMI2.1 compliant and HDCP 2.3 / 1.4 compliant

  • Supports audio extraction via Toslink & stereo

  • Supports resolution downscaling from 4K to 1080P

  • Supports default EDID and EDID from display or user

  • USB-C firmware update for expanding compatibility

  • Supports Dolby Digital, DTS-HD and Dolby TrueHD audio

2024
Q1

hd240 icon.png
HD250
HD250-2

HD250

HDMI & Phone Display Switch

  • Switch between 3 sources (HDMI and smartphone screen)

  • Support up to 4K@60 video

  • HDMI 2.0b compliant and HDCP 2.2 compliant

  • Supports USB-wired mirroring from your mobile

  • Supports wireless mirroring with Airplay and Miracast if using a USB wifi dongle

2024
Q1

hd240 icon.png
HD254
HD254-2
HD254-3

HD254

4x1 HDMI 2.0b Switch

  • Supports 4K2K@60 4:4:4 8bits and 8K4K@30 4:2:0 8bits and HDR* which is 4K2K@60 4:2:0 10bits**

  • HDMI 2.0b compliant and HDCP 2.2 / 1.4 compliant

  • The switcher can select any HDMI input by front panel button & IR remote control

  • Handy front panel button to switch any four HDMI/DVI sources

  • Front Panel LED indictors

  • Equalization on input ports and pre-emphasis on output port

2024
Q1

hd240 icon.png
HD255
HD255-2
HD255-3
HD255-4

HD255

5x1 HDMI 2.0b Switch

  • Supports 4K2K@60 4:4:4 8bits, and HDR 4K2K@60 4:2:0 10bits**

  • HDMI 2.0b compliant and HDCP 2.2 / 1.4 compliant

  • Wide frequency range: 25MHz~600MHz

  • Video bandwidth: 18Gbps

  • The switcher can select any HDMI input by front panel selection & IR remote control

  • Handy front panel button to switch any five HDMI/DVI sources

  • Front Panel LED indictors

  • Equalization on input ports and pre-emphasis on output port

  • Easy installation

2024
Q1

hd240 icon.png
HD256
HD256-2
HD256-3

HD256

4x1 HDMI 2.1 Switch

  • Supports up to 8K60, 8K30, 4K2K 120Hz, 1080P 240Hz 444 8bit

  • Supports HDR 10, HDR 10 plus, Dolby Vision HDR video pass-through

  • Supports VRR(Variable Refresh Rate) & ALLM(Auto Low Latency Mode)

  • HDMI 2.1 compliant and HDCP 2.3 and 1.4 compliant

  • The switcher can select any HDMI input by front panel selection and IR remote control

  • Handy front panel button to switch any four HDMI sources

  • Equalization on input ports and pre-emphasis on output port

2024
Q1

hd240 icon.png
HD257
HD257-2
HD257-3

HD257

4x1 HDMI 2.0a & USB-C Switch

  • HDMI2.0a compliant

  • Supports 4K2K@60 4:4:4 8bits and HDR, which is 4K2K@60 4:2:0 10bits

  • HDCP 2.2 and 1.4 compliant

  • The switcher can select any HDMI input by front panel selection & IR remote control

  • Compatible with USB Power Delivery 3.0 (PD 3.0) specification (5V/2A output max) on USB-C port

  • The switcher can select any HDMI input by front panel button and IR remote control

  • Handy front panel button to switch any four HDMI/USB-C sources

  • Front Panel LED indictors

2024
Q1

hd240 icon.png
CT1100-11
CT1100-12
CT1100-2

CT1100

4K HDMI 2.0 Extender over Single CAT6 with Bi-directional IR & PoC

  • HDMI 2.0 compliant

  • Supports 4K2K@60 4:4:4 8bits and HDR1, which is 4K2K@60 4:2:0 10bits2

  • Supports PoC (Power over Cable) which can power both units from TX or RX side with power supply

  • Supports HDMI input loopback

  • HDCP 2.2/1.43 & EDID Bypass

  • Pure unaltered uncompressed 7.1ch digital HDMI over Cat.5/5e/6 cable transmission

  • Supports full frequency IR signal from 20KHz to 60KHz and Bi-directional IR path-through

  • Wall mounting housing design for easy and robust installation

  • Video latency less than 100ms

2024
Q2

hd240 icon.png
CT2600
CT2600-2
CT2600-3

CT2600

4x4 HDMI 2.0 Video Processor with Matrix / Quad-View / Video Wall

  • Supports Matrix, Quad-Viewer & Video Wall mode function

  • Input resolutions support from 640x480 to 4096x2160@60Hz (4:4:4 8bits), interlaced or progressive

  • Output resolutions support up to 4K2K@60Hz (4:4:4 8bits)

  • Supports HDR, which is 4K2K@60 4:2:0 10bits

  • Supports limited seamless switching

  • Supports PIP, PBP, POP, full screen & quad-view display

  • Firmware upgradable through USB drive for support of new features and technology enhancements

2024
Q2

hd240 icon.png
